RSNV Medium Wave Cooled Handheld Infrared Observation Instrument Camera

Sales Engineer: Grace Gao

WhatsApp: +86 199 2997 5286

RSNV medium-wave refrigerated handheld infrared observation instrument is a multifunctional handheld observation device. It integrates medium-wave infrared refrigerated thermal imaging, a long-focus observation camera, a low-light search camera, laser ranging, an optional laser red dot indicator, a Beidou module, a magnetic compass, a storage module, a wireless transmission module, and an OLED micro-display component.Equipped with an observation system composed of various advanced sensors, signal processing circuits, and optical components, it enables long-distance all-weather observation and detection of targets during both day and night.

RSNV Medium-wave Camera

Specification Of RSNV Medium-Wave Infrared Camera
Infrared Module	Medium-Wave Cooling Handheld Infrared Observation Instrument Camera
Infrared Reconnaissance Detection Distance	≥8km
Recognition Distance	≥5km (Visibility 8km, Humidity 60%, Temperature Difference between Target and Background 6K, Side of a Medium - Sized Vehicle (4.6m×2.3m))
Focal Length	45 - 200mm Continuous Zoom
Focal Length Adaptation Range	20m - ∞
Detector Resolution	640×512
	Contrast, Brightness Adjustment, Image Polarity Conversion
Visible - Light Module
Visible - Light Observation Distance	≥8km (Visibility 12km, Humidity 60%, Side of a Medium - Sized Vehicle (4.6m×2.3m))
Focal Length	200mm
Resolution	1920×1080
Focal Length Adaptation Range	50m - ∞
	Automatic or Manual IR - CUT
Field of View	≥30.5°×20.5°
Focal Length	12mm
