Product Feature:
1. The truly field of view 120 degrees;
2.Continuously adjustable +/-3 diopter design, no need to change eyepieces;
3.Flip-Up On-Off;
4.Eyespacing locking makes operation more convenient;
5.no distortion , full screen clearly without distortion;
MODE |
BRI-GPNVG |
Generation |
Gen 2+/Gen3(optional) |
Magnification |
1X |
FOV(°) |
120x50 +/-2 ° Horizontal 120+/-2 ° Vertical 50 +/-2 ° |
Diopter |
(+1.5~-2.5) |
Capability |
Flip-Up On-Off |
Automatic Brightness Control |
YES |
Bright Light Cut-off |
YES |
Infrared Illuminator |
Built-in(850nm 20mW) |
IR Indicator |
YES |
Low Battery Indicator |
YES |
Battery type |
CR123Ax1 / CR123Ax4 Battery pack |
Power supply |
2.6-4.2V |
Battery capacity |
800-3200maH |
Optical distortion |
0.5% Max |
Eye relief |
30mm |
Pupil diameter |
8mm |
Operating temperature(℃) |
-40--+55℃ |
Humidity range |
5%-95% |
Waterproof |
IP65/IP67 |
Dimensions |
150x130x75 mm |
Weight |
495g(housing)/780g(finished) |
