RSNV BRI-GPNVG Head Mounted Quad Ground Panoramic Night Vision Goggles



Sales Engineer: Grace Gao

Email: grace@bri-elec.com

WhatsApp: 0086-199 2997 5286




Quad Ground Panoramic Night Vision Goggles

Product Feature:

1. The truly field of view 120 degrees;

2.Continuously adjustable +/-3 diopter design, no need to change eyepieces;

3.Flip-Up On-Off;

4.Eyespacing locking makes operation more convenient;

5.no distortion , full screen clearly without distortion;

Quad Ground Panoramic Night Vision Goggles

MODE

BRI-GPNVG

Generation

Gen 2+/Gen3(optional)

Magnification

1X

FOV(°)

120x50 +/-2 °

Horizontal 120+/-2 °

Vertical 50 +/-2 °

Diopter

(+1.5~-2.5)

Capability

Flip-Up On-Off

Automatic Brightness Control

YES

Bright Light Cut-off

YES

Infrared Illuminator

Built-in(850nm 20mW)

IR Indicator

YES

Low Battery Indicator

YES

Battery type

CR123Ax1 / CR123Ax4 Battery pack

Power supply

2.6-4.2V

Battery capacity

800-3200maH

Optical distortion

0.5% Max

Eye relief

30mm

Pupil diameter

8mm

Operating temperature(℃)

-40--+55℃

Humidity range

5%-95%

Waterproof

IP65/IP67

Dimensions

150x130x75 mm

Weight

495g(housing)/780g(finished)
