A Handheld Explosion - proof Gas Leak Detector is a portable device used to detect gas leaks in the environment. It has an explosion - proof function, making it suitable for use in hazardous areas where flammable and explosive gases may be present, such as in the petroleum, chemical, and gas industries. By promptly identifying gas leaks, it helps prevent dangerous incidents like explosions and fires.

Infrared performance
Sensor type	HgCdTe - cooled infrared focal plane detector
IR resolution	320×256
Detector pixel spacing	30μm
Working band	3.2 - 3.4μm
Spatial resolution	1.3mrad
Standard size	14.5"×11.6", Optional: 24"×18"
Focal length	38mm (fish - eye lens optional), 150mm
Focusing	Manual
Thermal image aperture	F/1.2
Sensor cooling	Stirling microcooler
Features
Image mode	-
Infrared image function	-
Image adjustment	-
Image enhancement	10 grades
Gas detection	After detecting gas, the target is automatically framed between two lines
Color palettes	8 kinds
LCD touch screen	5.5 inches, brightness 800cd/m², resolution 1280×720, LCD touch
Visible light camera	CMOS, 4 megapixels, built - in 1 LED fill light
Full - frame video recording	Visible light/infrared images support recording (MP4 format for visible light)
Fill light	-
Laser pointer	Class II, 1mW635nm red
Electronic zoom	3 - 8 times
File storage
Storage media	128G removable SD card + 128G EMMC
Picture format	.JPEG, storage path default EMMC, optional SD card
Video recording	.mp4 format, real - time recording, storage path default EMMC, optional SD card
Image stabilization	-
Interface
Video output	HDMI
Data interface	WIFI, Bluetooth, USB
Power interface	-
Power supply
Battery	Rechargeable lithium - ion polymer battery, about 3 hours at 25°C
Input voltage	DC12V
Start time	about 8 seconds
External battery	Optional external large - capacity battery, battery life up to 4 hours
Other
Set up	Date, time, temperature offset, display brightness, power - on mode
Environmental adaptability	- 20°C～+55°C (operating); - 40°C～+70°C (storage); ≤95%RH
Certification	Ex ic II CT4 explosion - proof certification, IP64 protection level
Appearance	-
Weight	≤2.2kg
Size	≤245×125×105mm (length×width×height, including lens)
Tripod installation	Standard 3/8 inch thread
Detectable gas	Methane, ethane, propane, butane, pentane, hexane, heptane, methyl bromide, ethyl bromide, methyl chloride, ethylene oxide, propylene oxide, dichloromethane, benzene, toluene, xylene, heptaldehyde, n - hexane, 1,3 - butadiene, trimethylbenzene, ethylene, propylene, 1 - butene, 1,3 - cyclopentadiene, 2 - methyl - 1 - butene, styrene, ethanol, isopropyl alcohol, acetone, n - butanol, methyl ethyl ketone, methyl - t - butyl ether, acetic acid, propionic anhydride, aniline, dimethyl ether, dimethyl sulfide, ethyl acetate, 2 - butanone, methyl isobutyl ketone, 4 - methyl - 2 - pentanone, tetrafluoroethylene, propylene, 3 - methylpyridine, etc.
