Thermal Imager
Detector Type
VOx Microbolometer
Resolution
640*512
Detector Pitch
8~14μm
Spectral Band
12μm
Frame Rate
50hz
Polarity
White/Black/Color
Thermal Sensitivity
30mk
Contrast/Brightness
Support
Image Denoise
Support
Image Enhancement
Support
E-Zoom
1.0×~8.0×
Infrared Optical
Focus Mode
Manual electric adjustment
Field of View
10°×8°
Focus Range
5m – Infinity
Daylight Camera
Sensor
CMOS
Resolution
1920*1080
Field of View
4.5°×3.5°
CMOS Camera
Resolution
800×600 8μm
Field of View
7.32°*5.86°
Laser Range Finder
Range Distance
6000m
Accuracy
5m
GPS/GNSS
Accuracy
5m
Compass
Digital Magnetic Compass
Yes
External Parameters
External Interface
WiFi/cvbs/hdmi/usb
Mount Adapter
1/4 NUC
Power Supply
Battery
Rechargeable Li-ion 18650
Operating Time
7H（@25℃）
AC/DC Adapter
220V, 50Hz
Environmental
MIL Standard
MIL-STD 810
Protection Level
IP67
Physical
Housing
Magnesium alloy
Suitcase Bag
provided
Observation Distance
Human IR Detection
3000 m
Human IR Recognition
1500 m
Vehicle IR Detection
5000 m
Vehicle IR Recognition
3500 m
Human Visible Detection
5000 m
Human Visible Recognition
3500 m
Vehicle Visible Detection
9000 m
Vehicle Visible Recognition
4500 m
Accessories
Tripod
Included
Battery Charger
Included
Extra Battery Set-1
Included
Warranty
Warranty Period
2 Years
