RSNV Short-Wave Infrared (SWIR) Camera integrates an InGaAs focal plane array with TEC cooling technology, offering a resolution of 640x512 pixels at 15μm pitch and exceptional sensitivity from 0.9μm to 1.7μm. Equipped with dual-stage TEC deep cooling, it effectively reduces readout noise for enhanced signal-to-noise ratio, making it ideal for low-light applications such as industrial inspection, scientific spectroscopy, and night vision surveillance. Engineered for seamless integration, the compact, modular design features high sensitivity, lightweight construction, low power consumption (<10W), and versatile connectivity options including GigE Vision, Camera Link, and USB 3.0, ensuring easy integration into OEM systems and compatibility with existing software frameworks. This combination of advanced detector technology, robust engineering, and user-friendly interfaces positions the RSNV SWIR Camera as a reliable solution for demanding SWIR imaging requirements across industrial, research, and defense sectors.

SWIR Camera

Model	RSNV BRI-STM640
Detector Performance	Resolution/Pixel Pitch	640×512，15μm
	Spectral Range	0.9μm~1.7μm
	Material	InGaAs
	Cooler Type	TEC second stage
System	Frame Rate	25Hz
	External Trigger	RS422
	Sync	Internal/Externalsync
	Integration Time	Manually
	E-Zoom	×2/×4
	Stable Power Consumption	≤5W@25℃
Performance	Non-linearity	≤1%
	Optical Non-uniformity	≤2‰
	Image Output Delay	≤1 frame
	Dynamic Range	≥63dB
Image	Exposure	Manual /Automatic
	Mirroring	Horizontal, vertical, and diagonal
	Image Gain	Manual /Automatic
	Image processiong algorithms	Non-uniform correction/image filtering/detail enhancement/ blind element correction
	Polarity	Black-hot/white-hot
	Crosshiar	Overlay
	Image output selection	Allows selection between raw /corrected image output
	Test image output	Support(checkerboard /grayscale patterns)
Protection	Overcurrent	Support
	Overvoltage	Support
	Undervoltage	Support
	Reverse polarity	Support
	Self checking	Support
Environmental Adaptability	Operating Temperature	-40℃~+70℃
	Storage Temperature	-45℃~+70℃
	Vibration	6.06g, random vibration, all axial
	Shock	80g, 4ms, post peak sawtooth wave, 3 Axis 6 direction
Interface	Optical interface	Standard C port
	Electrical interface	Analog video output: PAL
		Digital video output: CameraLink base
		Power supply: 9-26V DC,typical DC 12V
		Comunication: RS422
		External Sync: RS422&TTL

Applications

RSNV SWIR cameras can be widely used in various fields such as border and maritime defense, laser detection, astronomical imaging, security monitoring, biomedical applications, industrial inspection,semiconductor testing, material screening,machine vision, and scientific research.

Features

1. Manual/automatic exposure.

2. Horizontal, vertical, and diagonal mirroring.

3. Manual/automatic image gain.

4. Image processing algorithms: non-uniform correction, image filtering, detail enhancement, blind element

correction;

5. Black-hot/white-hot polarity switching .

6. crosshair overlay.

7. RS422 external synchronous input.

8. RS422 communication.

9. Blind element correction.

10.Allows selection between raw image output and corrected image output.

11. output for test images such as checkerboard and grayscale patterns.

12.Protection for overcurrent, overvoltage, undervoltage, and reverse polarity.

13. Self checking.

14.System status query features, including: simulated image state polarity, flip status; trigger mode; operating

frame rate; focal plane temperature; correction coefficient levels; integration time levels; image gray value mean,

maximum, minimum; cumulative operating time, power-on counts; firmware version number, component

number; software version number; algorithm switch status, etc.
