Product Description

The BRI-675 Long range distance measuring thermal infrared tactical night vision binocular is here to provide you with unprecedented capabilities at a fraction of the cost. Well designed a professional 75mm lens and 640x480px thermal sensor to provide sharp and clear images. MH675 Long range distance measuring thermal infrared tactical night vision binocular can record video and take photos directly to your micro SD card or stream them to your computer through the special video output cable. The MH675 Long range distance measuring thermal infrared tactical night vision binocular comes with more features than you will know what to do with at first, but soon you won’t know how you lived without them.

Specification

Main Parameter
Model			BRI-675
Detector type			Uncooled microbolometer
Thermal sensor resolution			640x480 px, 17μm
Spectral range			8~14μm
Frame rate			50Hz
NETD			<60mK@300k(F1.0)
Micro dispaly			800×600 OLED display
Image Processing
Startup Time			<5 s
Noise Reduction			Digital filtering
E-Zoom			2×/4×
Focus			Motorized(automatic) focusing
Image adjustment			White hot/black hot/Multiple Color Modes
Optical Parameter
Focal Length			75mm
F#			1.0
Field of View			8.3°×6.2° (H×V)
Video Recording and Storage
Photo Snap			JPEG
Video Recording			MPEG4
Video storage			Recording format 640×480,built-in 16Gb;
Video output			Analog :BNC Digital:USB2.0
WIFI			Yes
Observation Distance
Persons( Standing man)			Detection:2.0km Recognition:0.7km
Vehicle(NATO Tank)			Detection:3.5km Recognition:1.5km
Power Parameter
Power			1×26650 rechargeable lithium battery 3.7V @ 5000mAH
Power consumption			<3.0W(Observation operating )
Operating hours			Continuous working time:≥6hours
Environmental parameters
Seal standard			IP66
Operating Temperature			-30°C~+60°C(OLED)
Storage Temperature			-40°C~+70°C(OLED)
Humidity			5%~95%( Non-condensing)
Vibration			Sweep frequency:5-200-5Hz,G-force:2.5g
Impact			30g/11ms Half sine wave
Physical parameters
Product Weight			1.089kg (excluding Battery)
Dimension (mm)			220(L)×170(W)×85(H)
Mount Adaptor			Standard 1/4' tripod mounting
